Lubricated Rotary Screw Compressor 22 - 30 kW
CompAir L23 - L29, RS
The L-Series from CompAir
Well known in the industry for quality and reliability CompAir continuously develops the L-Series achieving cutting edge performance and efficiency. The L23-L29 range of lubricated screw compressors comprises of fixed speed and regulated speed (RS) models.
The CompAir L23–L29, RS is a range of lubricated rotary screw air compressors designed for industrial compressed air applications. The series includes both fixed-speed and regulated-speed (RS) models with motor ratings from 22 kW to 30 kW.
You can find the official product page here:
CompAir L23–L29, RS Product Page
Key features
Power range: 22–30 kW
Models: L23, L26, L29 (fixed speed) and L23RS, L26RS, L29RS (variable speed)
Pressure range: Typically 5–13 bar (depending on model)
Air delivery: Approximately 2.98–5.52 m³/min, depending on pressure and model
Premium in-house airend with low rotational speed for improved efficiency
IE3 high-efficiency electric motor
Compact footprint with low maintenance requirements
Optional integrated heat recovery system
Compatible with accessories such as refrigerated dryers, filters, condensate drains, and nitrogen generators.
Controller
The compressors are equipped with the Delcos Pro or Delcos Pro SE controller, which provides:
Pressure and temperature monitoring
Service reminders
Fault history
Remote start/stop
Auto restart after power failure
RS485 Modbus RTU communication
(On newer versions) data logging and Ethernet connectivity options.
Typical applications
Manufacturing plants
Automotive workshops
Food and beverage processing
Textile industries
General industrial compressed air systems requiring reliable, continuous-duty operation.
If you need it, I can also provide:
the complete technical specification table (flow, pressure, dimensions, weight, and noise levels),
the product brochure (PDF), or
a comparison between the L23, L26, and L29 RS models.
Benefits
Engineering Excellence
Benefits to you:
High reliability and high quality compressed air
Superior energy efficiency
High flexibility
Small footprint
Low maintenance & servicing costs
Engineering excellence
Premium efficiency airend
Time proven inverter concept
iConn industry 4.0 Solution
Integrated heat recovery
Water Separator
Compressed Air Filter
Condensate Drain Solution
Compressed Air Refrigerant Dryer
Heatless Desiccant Dryers
Heat Regenerative Desiccant Dryers
Nitrogen Generator
SmartAir Master Multi Compressor Controllers
Design
A Design Concept Based on Quality
Large Surface after Cooler
High Performance Separator Filter
High Efficiency Electric Motor
Thermostatically Controlled Motor Driven Fan
Highest Quality Connections
Controller
Delcos Pro Compressor Controller
The control system ensures reliable operation and protects the investment by continuously monitoring operational parameters. The Delcos Pro also has the capability to have programmable inputs and outputs, control additional equipment as well as providing the all relevant information in clear readable text:
Discharge/line pressure display
Air/oil temperature display
Total hours run and under load
Service due indicator
Enhanced fault log monitor
Real time clock
Timer controlled stop/start
Remote start/stop
Auto restart after power failure
Second pressure setting
Status indication
RS485 - Modbus RTU
The pressure setting can be easily adjusted via the controller.
